It is not my intent here to create a full tutorial on using graph databases; I just want to convey enough understanding so that you might see why they are a better fit for placement than a relational DB.

The most basic thing to understand is that your whiteboard design is your database design. Here’s what I mean by that:

This is the general form of the CREATE statement in Neo4j’s declarative language Cypher:

CREATE (obj1)-[relates_to]->(obj2)

And here is the specific code for creating that in Cypher:

CREATE (cnode:ComputeNode)-[:PROVIDES]->(mem:MEMORY_MB {
    total: 10000, used: 2000})
RETURN cnode, mem

Note that the syntax is close to ASCII diagramming, using parentheses to enclose nodes, square brackets to enclose relationships, dashes to connect them, and arrows to indicate the direction of the relationship. Also note that nodes and relationships can have properties; here I gave the memory a ‘total’ of 10,000, and a ‘used’ value of 2000. These can be used to filter results to only those that have the necessary amounts. I used the Placement standard resource class ‘MEMORY_MB’ for the RAM to make it more familiar.

Neo4j comes with a browser that lets you visualize your data. So when I ran the above code in the browser, I get this back:

Ok, I guess at this point it seems almost toy-like. So here’s something a bit more interesting:

This is a compute node (purple) that provides disk (green), and contains two NUMA nodes (yellow), each of which provides VCPU (orange), RAM (grey), and VFs (pink). The model as stored in the DB matches the real world, and doesn’t require expensive JOINs to retrieve.

And finally (just to show off a little),  I created 500 compute nodes and associated them with aggregates. In Nova/Placement lingo, an ‘aggregate’ is a way to associate things that have something in common. Here’s what one such model looks like:

The pink dot in the center is an aggregate, with purple compute nodes attached to it, and attached to those compute nodes are green disks, yellow memory, grey VCPU, and red VFs. And though they are faint, the lines connecting those things are the key to why this works so well: you can traverse these relationships in any direction in a single query– no joins required. I’ll give some specific examples of querying nested and shared resources in the next post in this series.

The work on the OpenStack Placement service has been getting more and more complex in the last few months, as the service has matured to handle more complex resources. At first, things were pretty basic: you had a ResourceProvider, and it had Inventory of various ResourceClasses. You told Placement how much you needed of one or more ResourceClasses, and it returned those providers that had enough to meet your request. Simple.

This was the world where the ResourceProviders were simple computers, and the resources were that computer’s RAM, disk, and VCPUs. You wanted a VM with so much RAM, disk, and VCPU, and Placement returned those compute nodes that could provide that. This was all implemented internally using common relational database techniques, and it was simple and fast.

Now we are starting to model more complex resources, and the complexity is growing rapidly. We have sharing providers, with the canonical example being a shared disk whose storage can be consumed by a number of compute nodes, so there needs to be a way to model that. There are also nested providers, such as a network virtual function (VF) that is provided by a NIC that is part of the computer. This means that when you ask Placement for an instance that has a VF, it has to know the relationship between the compute node (root provider), the NIC (resource provider), and the VF (resource), and return the whole structure. These nested relationships aren’t limited to just one level; when you add in things such as NUMA, there can be many such nesting levels.

The modeling complexity has now grown significantly, and the ability to implement this complexity using relational databases, while certainly still possible, requires solutions that are less and less readily comprehensible for anyone looking at the code for the first time. I worked as a SQL DBA for several years, so I’m not a stranger to SQL, but I need to read the code several times, usually with a pen and paper to diagram things, before I truly understand what each bit is doing. If you’d like to see what I mean, peruse the _get_trees_matching_all() method of nova/api/openstack/placement/objects/resource_provider.py. It’s truly amazing that that code works as well as it does, but drives home the point that overly complex solutions indicate that there is a poor fit between your model and the thing that you’re trying to model.

No database will ever get rid of the complexity, of course, but some are much better suited to handling relations of these types than traditional relational databases. At the last PTG, these discussions, as well as the drawings that were made to illustrate the relationships, made me think about another type of database: graph databases. So I started playing around with the most popular one, Neo4j. Graph databases use a relationship-first approach to storing and accessing data, and this seemed to better model the needs of Placement than an RDBMS.

I do realize that it is too late for OpenStack Placement to change something as fundamental as their data storage model. But after playing around with Neo4j for a little while, it’s obvious that it fits the problem domain better than MySQL does. I’ll demonstrate this in the next post in this series. But the current state of Placement reminds me of the old saying  “when all you have is a hammer…”.

The ‘cloud’ in cloud computing derives from the amorphous location of your resources. Sure, you have a virtual server, but all you really know is that it’s somewhere on your cloud provider’s hardware, and you can reach it at a certain IP address. You generally don’t care about its exact location.

There are times, though, when you might care. High Availability (HA) designs are a good example of this: you want to avoid putting all your eggs in one basket, so to speak. You don’t want your resources in the same failure domain, so that when there is an outage, it is likely to only affect one part of that provider’s cloud, while other parts remain functional. In these cases, you would want to request that your VMs are placed in different locations so that in the event of an outage in one part of the cloud, the rest should remain functional.

After many discussions about this recently in the #openstack-nova IRC channel, I’ve thought about how to approach this, and wanted to write down my ideas so that others can comment on them.

The placement service already has the concept of aggregates, which are used primarily for determining which resources can be shared with other resources. I think that we can use aggregates for affinity modeling, too. Note: Placement aggregates are not Nova aggregates!

A resource’s location can be described at many levels. In the example of a VM, it is located on a host machine. This machine is located in a rack of machines. These racks are located in rows. Rows are located in rooms. Rooms are located… well, you get the idea. These more or less correspond with sharing the same network segments, power sources, etc. The higher you go up this nesting, the more isolated things are from each other.

As an operator of a cloud, you define which of these groupings you want to give your users the ability to choose from. You could, of course, choose to expose every possible layer to your users, but that may not be practical (or necessary). So for this example, let’s assume that users can specify affinity or anti-affinity at the rack, row, and room levels. Here’s how I think this can be achieved in placement:

Define an aggregate for each rack, and then add all the host machines in that rack to that agg. Once that’s done, it’s a simple matter to determine if a potential candidate for a new VM is in the same rack or not by simply testing membership in that aggregate.

Next, define an aggregate for the row. Add all the hosts in that row to this row aggregate. Yeah, that sounds cumbersome, but really, we could create a simple tool that lets the operator select the racks for a row, and iteratively adds the hosts in those racks to that aggregate. Once again, when this is done, it is simple to determine if a candidate is in a given rack by simply checking if it is a member of that rack’s aggregate. The same pattern would hold for defining the room aggregate.

While this would indeed require some setup effort by operators, I don’t think it’s any worse than other proposals. These definitions would be relatively static, as the layout of a DC doesn’t change too often, so the pain would be mostly up front, with the occasional update necessary.

Now we start to handle requests like “give me an instance that has this much RAM, VCPU, and disk, but make sure it’s in a different row than instance X”. To do this, we just need to look up what row aggregate instance X is in, and filter out those hosts that are also in that same aggregate. The naming of these grouping levels would be left to the operator, so they could be in control of how granular they want this to be, and also make sure that their flavors match these names.

This idea doesn’t address the “soft affinity” issue, which basically says “give me an instance in Row R, but if there isn’t any candidate found there, give me one in the closest row to that”. The notion of “closest”, or any sort of “distance”, for that matter, isn’t really something that is clearly defined, as it could be physical location, or number of network switches, or pretty much anything else. But if it is determined to be a priority to support, perhaps we could add a column to contain some sort of distance/location identifier to the PlacementAggregate table. Or maybe we could think up some other way of defining relative location. In any case, I think it would be a poor choice to design an entire system around a relatively esoteric requirement. We need support for robust affinity/anti-affinity in Placement, and I think we can get this done without adding more tables, relationships, and complexity.
